Wire Tracing / Mapping

This service corrects the labelling of distribution boards in line wth the national rules of electrical installations I.S. 10101 2020.  It is ideal for situations where documentation has gone missing or changes have not been documented over time.  Spectrocity uses the latest wire tracing technology, which can be performed on live circuits.  This is particulary useful for operations that cant have interuptions to the supply.  The benefits of a well labelled systems and load schedules are as follows:

• Compliance with the national rules of electrical installation I.S. 10101
• Rapid recovery froms faults
• Increased safety
• Isolation of supplies
• Avoiding interuption of critical process.
• Simplifies future design modifications.

Electrical Services Design

Load Schedules

Load schedule templates are updated during the tracing process and added to panels on completion.  Labels are placed end to end on circuits, for maximum tracibility.
